Piston compressor GENESIS seriesairelectricstationary
Add to favorites
Compare this product
Characteristics
- Technology
- piston
- Type
- air
- Power source
- electric
- Portability
- stationary
- Lubrication
- oil-free
- Other characteristics
- tank-mounted
- Tank volume
270 l, 500 l
(71.3 gal, 132.1 gal)- Pressure
8 bar, 10 bar, 13 bar
(116.03 psi, 145.04 psi, 188.55 psi)- Flow
Min.: 125 l/min
(33.02 us gal/min)Max.: 3,650 l/min
(964.23 us gal/min)- Power
Min.: 5.5 kW
(7.48 hp)Max.: 22 kW
(29.91 hp)- Length
1,150 mm, 1,935 mm, 1,939 mm
(45.28 in, 76.18 in, 76.34 in)- Width
665 mm, 805 mm
(26.18 in, 31.69 in)- Height
1,687 mm, 1,689 mm, 1,841 mm
(66.42 in, 66.5 in, 72.48 in)- Weight
Min.: 338 kg
(745.2 lb)Max.: 640 kg
(1,411 lb)- Noise level
Min.: 62 dB
Max.: 70 dB
Description
Discover the power and efficiency of the Formula and Genesis rotary screw compressor range, designed for optimal performance and reliability, delivering high-quality compressed air for all your Industrial needs.
RELIABILITY
Easiness without compromizing on completeness, robustness, efficiency and outstanding reliability provided by high performance air ends with superior FAD efficiency.
dry and clean air
air quality
Enjoy a solution equipped with a built-in dryer and an efficient filtration system. The result is simple: dry and clean air suitable for most of the industrial applications.
EASE OF USE
Full control
The controllers provide easy access to menus and key performance indicators, remote control (up to 6 compressors), programmed maintenance, fault log, and other functions.
plug and play solution
easy maintenance
The service items are positioned for easy and fast maintenance. An external oil level indicator, long service intervals, and smart maintenance kits enhance the user-friendly experience.
