Electric beveling machine ART.15

portablesheetautomatic

Power supply Input 400 | 50 | 3 Output 48 | 50 | 3 Acoustic emission 68 dB Overall dimension (Width x Depth x Height) 400 x 250 x H. 260 mm Weight standard machine 16 kg Chamfer - bevel unit Bevel dimension (diagonal) 0 ÷ 20 mm Milling cutter diameter ø 80 mm Quantity of widia insert milling cutter 20 No. Widia insert type/code SPUN 12 03 08 ISO Support table dimension 80 x 250 mm Peripheral speed 12 m/sec Standard Equipments Machine respect CE stamp of compliance - Machine with CE conformity mark made respecting the requirements of the most recent directives concerning it. - Machine complete with instruction manual complete with CE conformity certificate, test sheet and exploded view with relative spare parts list. - Machine equipped with a set of service keys suitable for the adjustment and maintenance of the machine. Technical general information - Hardened, case hardened, ground and grooved guides for prolonged resistance to friction. - Axial displacement of the guides for full use of the insert surface. - Tilting beveling guide with graduated indicator for bevels from 15 ° to 45 °. - Bevel size adjustment handwheel. - Cutter body complete with 20 widia inserts.
