Managed ethernet switch EKI-7708E-4FP
8 portsDIN rail mountedwall-mount

managed ethernet switch
managed ethernet switch
managed ethernet switch
managed ethernet switch
Add to favorites
Compare this product

Characteristics

Type
managed
Number of ports
8 ports
Mounting
DIN rail mounted, wall-mount
Other characteristics
PoE, SFP+, fast, RJ45
Applications
industrial

Description

- 4 x IEEE 802.3 af/at PoE Fast Ethernet ports + 4 SFP ports - SFP socket for Easy and Flexible Fiber Expansion - Redundancy: X-Ring Pro (ultra high-speed recovery time < 20 ms), RSTP/STP (802.1w/1D) - IXM function enables fast deployment - Security: 802.1x (Port-Based, MD5/TLS/TTLS/PEAP Encryption), RADIUS - Management: SNMP v1/v2c/v3, WEB, Telnet, Standard MIB, Private MIB - NEMA TS2 for Traffic Control - EN50121-4 approval for Railway trackside deployment - -40 ~ 75°C wide-range operating temperature (EKI-7708E-4FPI) - Dual 48 VDC power input and 1 relay output EKI-7708E-4FP/4FPI supports 4 Fast Ethernet IEEE 802.3 af/at PoE ports and 4 SFP (mini-GBIC) ports. They can provide up to 30 watts per port to fulfill high power consumption PD (Power Device) requirements. They are embedded with Advantech’s IXM function, which can benefit users for fast deployment and can dramatically save engineers time and cost. The EKI-7708E series also supports NMS to help IT managers with networking maintenance and failure prevention. Finally, the EKI-7708E series is equipped with X-Ring Pro which can achieve ultra high speed recovery time of less than 20 ms to ensure network stability. The switch also features a wide -40° to 75°C operating temperature (EKI-7708E-4FPI) and NEMA TS2 rating, making the switch an ideal solution for use in traffic applications. EKI-7708E-4FP/4FPI has successfully passed the EN50121-4 European railway standard requirements for emissions and railway platform and trackside deployment.
