Ceiling-mounted fan AM seriesaxialcoolingsteel
Add to favorites
Compare this product
Characteristics
- Installation
- ceiling-mounted
- Configuration
- axial
- Function
- cooling
- Material
- aluminum, steel
- Other characteristics
- industrial, commercial
- Air flow
Max.: 12,750 ft³/min
(361.04 m³/min)Min.: 3,700 ft³/min
(104.772 m³/min)- Diameter
16 in, 22 in, 30 in
- Rotational speed
1,150 rpm, 1,725 rpm
(7,226 rad.min-1, 10,838 rad.min-1)- Noise level
Max.: 77 dB
Min.: 60 dB
Description
Our ceiling mount fans are useful in many different applications. They may be attached to a C, I or Wood Beam.
We use high-grade, zinc-plated hardware and a durable powder coated finish for long-lasting performance in industrial and commercial settings.
Ceiling mounts are available with our 16″, 22″ or 30″ diameter blade fans.
AirMax® Fans specs:
16 gauge steel dual venturi/housing
1 phase or 3 phase motor
High-grade zinc-plated hardware
Aluminum blades
7 gauge steel mounting material
3/8 inch spaced concentric steel wire guards that meet OSHA requirements
Powder coated for durability
Ceiling Mount Fans are designed to be attached to a beam. Useful in warehouse cooling or on pick-lines where you need to push air from above.
Additional information
Size -
16" Fan, 22" Fan, 30" Fan
HP -
1/2 HP, 1 HP, 2 HP, Let's Discuss
Motor Options -
1 phase, 3 phase, Let's Discuss
Accessories -
Mister, Indoor Oscillator, Outdoor Oscillator, None
