Vector control AC drive PowerFlex® 700S series
verticalNEMA 1IP20

vector control AC drive
vector control AC drive
Add to favorites
Compare this product


Characteristics

Type
vector control
Mounting
vertical
Protection class
NEMA 1, IP20
Other characteristics
high-performance
Power

Max.: 1,500,000 W

Min.: 750 W

Current

Max.: 1,500 A

Min.: 2 A

Description

PowerFlex® 700S AC Drives offer optimized integration for the most demanding stand-alone, coordinated drive control and drive system applications. The PowerFlex 700S AC drive with the DriveLogix™ option combines the powerful performance and flexible control of PowerFlex AC drives with a high-performance Logix engine to produce a highly functional, cost-effective drive and control solution. Features • Power Ratings • 200…240V: 0.75…66 kW / 1…100 Hp / 4.2…260 A • 380…480V: 0.75…800 kW / 1…1250 Hp / 2.1…1450 A • 500…600V: 1…1600 Hp / 1.7…1500 A • 690V: 50…1500 kW / 52…1500 A • IP20 NEMA/UL Type 1 and IP21 NEMA/UL Type 1 • V/Hz control, Vector Control with FORCE™ Technology, and Permanent Magnet Motor Control • Zero Stacking™ Drives or side-by-side mounting conserves panel space and reduces installation costs • Pull-apart control terminal blocks allow for easy wiring and quick disconnect • Optimized global voltage settings allow quick setup anywhere in the world • Common bus capability • SynchLink™ fiber optic link for a high level of drive coordination and data transfer • AC or DC common bus configurations for stand-alone or multiple drive solutions • User function library provides logic functions without a PLC • Optional DriveLogix™ embedded control for application programmability and control of auxiliary functions • Configuration and programming via optional integral LCD keypad, remote keypad, or software • Premier Integration with PowerFlex® AC drives uses the Logix control platform to simplify parameter and tag programming and reduces development time • Available Embedded Safety Options
