Diaphragm accumulator H series

Maximum working pressure (PS): 300 bar Test pressure (PT): PS x 1.43 bar Maximum préchargé admissible: 210 bar Body: made in painted carbon Steel Standard nitrogen valve : W UNF Constructive methodology: two différent parts united whit a spécial threading that under condition of dynamic pressure tends to self- bloc k Working température for standard exécution: from - 20°C to + 90ÙC Standard diaphragm: can be used with minerai oils and non corrosive fluids Installation: in every position Compression ratio: - recommended: P2/P0 = 2.5 - maximum : P2/P0 = 6 Mechanical life: the number of cycles is inversely proportional to the increase compression ratio Warranty: see dedicated page Spare parts: see dedicated page Available : • HST..LT with diaphragm suitable for working températures to -40 ‘C • HST .. M: rechargeable with nitrogen valve M28x1.5 • HST .. V: not rechargeable with a fixed nitrogen preload in the factory - HST .. S: separator of fluid - hydraulic exécution Zi BPS
