Transportable asphalt plant ABT SpeedyBatch 2.0

mobilestationary

Product type
Batch asphalt-mixing plant (batch asphalt-mixing plants)

Overview
The ABT SpeedyBatch 2.0 is a mobile, container-dimension batch asphalt-mixing plant designed for rapid deployment and simplified transport. Integrated cable channels within protected catwalks and support-structure-mounted reclaimed and external filler silos reduce on-site handling and eliminate the need for elevators in many configurations. Models cover a production range suitable for medium to large-scale paving projects.

Key features

• Production capacity: 180 – 340 t/h depending on model
• Maximum recycling rate: up to 50% RAP
• Plant configurations: Stationary or Transferable (mobile)
• Container-dimension configuration for simplified transport and rapid setup
• Integrated cable routing in protected catwalks to streamline logistics
• Reclaimed and external filler silos integrated into the support structure (reduces installation complexity)

Highlights

• Model variants tailored to high-volume projects (ABT SpeedyBatch 180 / 260 / 340)
• Fast assembly and modular deployment for temporary or permanent installations
• Support for sustainable operation: high RAP rates, warm-mix options, low-emission burner packages and noise-reduction measures

Specifications table (selected items)
Model — Recycling system — Production capacity [t/h] — Dryer drum type / Burner — Filter type [surface m2] — Screen type [N° Sel.] — Hot mineral silo capacity [t] — Mixer type / Batch capacity kg [t/h] — Ready mix silo capacity [t]
ABT SpeedyBatch 180 — RAC 30 / RAH 50 / RAH 35 / RAH 50 2nd-gen / RAC — 180 — T-2080 / 10 | 10 MW — AFA 2460 [480 m2] — VA 1536 [4-5] — Up to 70 — Amix 1.22 2200 kg [187] — Up to 40
ABT SpeedyBatch 260 — RAC 30 / RAH 50 / RAH 35 / RAH 50 2nd-gen / RAC — 240 — T-2390 / 16 | 14 MW — AFA 3062 [724 m2] — VA 1840 S [4-5] — Up to 86 — Amix 2.30 3300 kg [281] — From 30t underneath up to 112t lateral
ABT SpeedyBatch 340 — RAC 30 / RAH 50 / RAH 35 / RAH 50 2nd-gen / RAC — 340 — T-25100 / 20 | 18 MW — AFA 3075 [885 m2] — VA 2050 S [5-6] — Up to 90 — Amix 2.40 4300 kg [340] — From 30t underneath up to 112t lateral

Ammann technology and options
Ammann integrates intelligent automation and digital platforms for predictive maintenance and process control. Available options include support for alternative fuels and low-emission burners, modular add-ons, high-RAP recycling systems, warm-mix technologies, noise reduction packages, zero-waste features and advanced emission-control solutions to meet regulatory and sustainability requirements.

Technical specifications

• Brand: Ammann
• Model family: ABT SpeedyBatch 2.0 (models: 180 / 260 / 340)
• Production capacity: 180 t/h (180 model) • 240 t/h (260 model) • 340 t/h (340 model)
• Max recycling rate: up to 50%
• Plant configuration: Stationary or Transferable; container-dimension configuration for mobility
• Dryer / Burner examples: T-2080 / 10 (180) • T-2390 / 16 (260) • T-25100 / 20 (340)
• Filter type / area examples: AFA 2460 [480 m2] (180) • AFA 3062 [724 m2] (260) • AFA 3075 [885 m2] (340)
• Screen types: VA 1536 [4-5] (180) • VA 1840 S [4-5] (260) • VA 2050 S [5-6] (340)
• Hot mineral silo capacity: up to 70 t (180) • up to 86 t (260) • up to 90 t (340)
• Mixer types & batch capacities: Amix 1.22 2200 kg [187] (180) • Amix 2.30 3300 kg [281] (260) • Amix 2.40 4300 kg [340] (340)
• Ready-mix silo capacity: Up to 40 t (180) • From 30 t underneath up to 112 t lateral (260 & 340)
• Transportation & installation: Designed for rapid deployment; cables integrated into catwalks; reclaimed and filler silos integrated into support structure to reduce transport complexity
