Propeller fan AIRBEAMceiling-mountedventilationfor air circulation
Add to favorites
Compare this product
Characteristics
- Configuration
- propeller
- Type
- ceiling-mounted
- Function
- ventilation, for air circulation
- Supply voltage
- 220VAC
- Drive mechanism
- electrically-powered
- Other characteristics
- compact, low-speed, large-diameter, high-performance, low-noise, high-flow
- Air flow
Min.: 47.706 m³/h
(1,684.721 ft³/h)Max.: 47.706 m³/h
(1,684.721 ft³/h)- Diameter
Min.: 1,170 mm
(46.063 in)Max.: 1,170 mm
(46.063 in)- Rotational speed
Min.: 0 rpm
(0 rad.min-1)Max.: 200 rpm
(1,257 rad.min-1)
Description
Overview
The AIRBEAM fan is designed for environments requiring discreet yet effective ventilation, combining a slim profile with high air performance. Ideal for commercial spaces, modern offices and areas with medium or low ceilings where both appearance and function are required.
Key features
Dimensions / Variants
Technical specifications
The AIRBEAM fan is designed for environments requiring discreet yet effective ventilation, combining a slim profile with high air performance. Ideal for commercial spaces, modern offices and areas with medium or low ceilings where both appearance and function are required.
Key features
- Compact "ray"-type mounting structure that occupies minimal space
- Energy-efficient, low-consumption motor
- High airflow for its size
- Easy installation for indoor and outdoor use
- Aesthetic design that integrates into the environment
- Simple maintenance
- Quiet operation
Dimensions / Variants
- Available diameter: 1.17 m
Technical specifications
- Power: 1000 W, 220 VAC - 480 VA III, 50/60 Hz
- Maximum speed: 200 RPM
- Airflow: 47.706 m3/h
- Coverage: -
- Weight: 50 kg
- Diameter: 1.17 m
