High-flow fan AIRPIVOTceiling-mountedwall-mountedlow-noise
Add to favorites
Compare this product
Characteristics
- Type
- high-flow, ceiling-mounted, wall-mounted, low-noise
- Configuration
- orientable
- Function
- destratifier, ventilation, for air circulation, homogenizing
- Applications
- industrial
- Other characteristics
- with adjustable blades, radio-controlled, large-diameter
- Air flow
Max.: 43,200 m³/h
(1,525,593.602 ft³/h)Min.: 16,800 m³/h
(593,286.401 ft³/h)- Diameter
Max.: 1,500 mm
(59.055 in)Min.: 900 mm
(35.433 in)- Rotational speed
Max.: 700 rpm
(4,398 rad.min-1)Min.: 400 rpm
(2,513 rad.min-1)
Description
Presentation
The AIRPIVOT is an industrial directional ceiling fan designed to provide adjustable airflow orientation and intelligent speed control for medium to high ceiling industrial or commercial spaces. It enables adjustment of both speed and airflow angle to target specific zones and improve overall air distribution.
Key features
Options / Variants
Technical specifications
The AIRPIVOT is an industrial directional ceiling fan designed to provide adjustable airflow orientation and intelligent speed control for medium to high ceiling industrial or commercial spaces. It enables adjustment of both speed and airflow angle to target specific zones and improve overall air distribution.
Key features
- Adjustable airflow direction and angle.
- Touch and remote speed control.
- Directed, flexible coverage for targeted zones.
- Designed for continuous professional use.
- Mounting configured for wall or ceiling installations in medium to high ceilings.
Options / Variants
- Diameter: 0.9 m, 1.2 m, 1.5 m.
- Color: Black, Grey.
Technical specifications
- Power: 0.5 kW (variants also at 0.95 kW).
- Power range: 0.5–0.95 kW.
- Speed (variants): 400 rpm, 450 rpm, 700 rpm; range 400–700 rpm.
- Air flow (variants): 16,800 m3/h; 25,200 m3/h; 43,200 m3/h; range 16,800–43,200 m3/h.
- Weight: 80–105 kg (variant-specific values: 80 kg, 92 kg, 105 kg).
- Mounting format: wall or ceiling with adjustable orientation (for medium to high ceilings).
- Operation: low-noise operation adapted to large spaces with directional airflow control.
