Water-based fire extinguishing system PIRANHA®
Add to favorites
Compare this product
Characteristics
- Options
- water-based
Description
Overview
The PIRANHA dual-agent restaurant fire suppression system combines the rapid flame knockdown of a PRX wet chemical agent with the fast cooling action of water. Designed as a pre-engineered solution, it is suited to environments such as casual and fine dining, fast-food chains, culinary schools, sports venues and upscale lodging facilities. The system uses sequential discharge—PRX liquid agent for immediate flame knockdown and securing, followed by water to cool cooking media and reduce reflash risk.
Features
Benefits
Technical Resources (selected documents)
Technical specifications
The PIRANHA dual-agent restaurant fire suppression system combines the rapid flame knockdown of a PRX wet chemical agent with the fast cooling action of water. Designed as a pre-engineered solution, it is suited to environments such as casual and fine dining, fast-food chains, culinary schools, sports venues and upscale lodging facilities. The system uses sequential discharge—PRX liquid agent for immediate flame knockdown and securing, followed by water to cool cooking media and reduce reflash risk.
Features
- UL and ULC listed; CE marked
- Two nozzle styles to cover a wide range of cooking appliance hazards
- Rapid flame knockdown using PRX liquid fire suppressant
- Reliable cartridge actuation
- Overlapping nozzle coverage for flexible appliance layouts
- Dual-agent configuration (PRX liquid agent plus water)
- Reduced agent storage requirements versus single-agent systems
Benefits
- Approximately twice the coverage area compared with conventional single-agent systems
- Up to 15× faster cooling of cooking oils versus single-agent systems
- Uses about 60% less chemical agent than comparable single-agent systems
- Flexible overlapping protection for diverse appliance arrangements
- Smaller and fewer agent storage tanks required per installation
- Meets multiple global approvals: UL/ULC listed; CE marked; ASSE, LPCB, IAMPO approvals
Technical Resources (selected documents)
- PRX Liquid Fire Suppressant Data Sheet
- ANSUL Effective Protection for Restaurant Cooking Equipment (Brochure)
- ANSUL PIRANHA Product Overview (brochures/datasheets)
- PIRANHA Restaurant Fire Suppression Systems Datasheet
- Restaurant System Flushing Concentrate Datasheet
Technical specifications
- System type: Pre-engineered kitchen fire suppression, dual-agent (PRX wet chemical + water)
- Listings/approvals: UL listed, ULC listed, CE marked; approvals include ASSE, LPCB, IAMPO
- Nozzle options: Two nozzle styles with flexible overlapping coverage
- Actuation: Cartridge-operated discharge
- Performance: ~2× coverage vs. single-agent systems; up to 15× faster oil cooling; ~60% reduction in chemical agent use
- Applications: Casual and fine dining, fast food, culinary schools, sports complexes/stadia, four- and five-star lodging
