4-20mA data-logger LGS34-001
radio frequencywithout displayloop

4-20mA data-logger - LGS34-001 - AOIP - radio frequency / without display / loop
4-20mA data-logger - LGS34-001 - AOIP - radio frequency / without display / loop
4-20mA data-logger - LGS34-001 - AOIP - radio frequency / without display / loop - image - 2
4-20mA data-logger - LGS34-001 - AOIP - radio frequency / without display / loop - image - 3
Add to favorites
Compare this product
Go to the AOIP website for more information

Characteristics

Measured quantity
4-20mA
Connector type
radio frequency
Display
without display
Applications
loop
Other characteristics
battery-powered, with connector, IP65, current loop

Description

Product overview
The LGS34-001 is a 4-20 mA data logger for remote acquisition and transmission of industrial measurements. It provides real-time monitoring, local recording and time-stamped storage for later download. The recorder is housed in an IP65 aluminium enclosure and is designed for outdoor and industrial temperature ranges.

Operating modes
  • Monitoring: continuous real-time transmission to PC; if a measurement is not received it is stored in internal memory and forwarded at the next communication opportunity.
  • Recording / Restitution: onboard logging of measurements with the ability to download the full dataset to a PC for post-processing and analysis.


Included / fitted items
  • IP65 aluminium enclosure
  • ½ wave RF antenna (included)
  • AA Lithium Thionyl battery (included) with plug-in connector


Certification
CE

Additional notes
Designed for outdoor and industrial temperature ranges. Ensure correct tightening of probe and antenna seals to maintain IP65 rating.

Technical specifications
  • Model: LGS34-001
  • Interface: 4–20 mA
  • Number of inputs: 1
  • Measurement range: 0…20 mA
  • Input impedance: 62 Ω
  • Accuracy (without sensor): ±0.001 mA
  • Resolution: 0.0006 mA
  • Sensor power supply: Not applicable
  • Temperature sensor: EYES
  • Operating temperature: -40°C … +85°C
  • IP rating (logger and connector): IP65 (valid if probe and antenna seals correctly tightened)
  • Battery: AA Lithium Thionyl (included) with plug-in connector
  • Autonomy: Up to 3 years (at 25°C, measurement every 10 minutes; actual value depends on use)
  • RF antenna connector: SMA
  • Antenna: ½ wave antenna (included)
  • RF range (open field): 100 m to 1 km (depends on receiver antenna)
  • Memory capacity: 32,256 measurements with date and time
  • Time/date resolution: 1 s
  • Time deviation: ±2 min/month at 25°C
  • Data retention: 100 years
  • Integrated ILS functions: wake-up in hibernate, forced measurement outside set frequency
  • Housing: 4 mm aluminium
  • Mounting: fixing plate supplied (4‑point screw) or strap-through holes
  • Colour: Grey (aluminium)
  • Dimensions (without antenna): 98 mm × 64 mm × 34 mm
  • Weight: ~280 g
  • Labels: 2 stickers — top (product range) and side (full reference and serial number)
