Thermocouple LGR64-001

in metal housingwirelessbuilt-in transmitter

Overview
The LGR-64 is a temperature and humidity sensor/logger designed for both real-time monitoring and recording/playback applications. In monitoring mode the device transmits measurements to a PC in real time and buffers data when communication is interrupted. In recording/playback mode the logger stores measurements in internal memory for later download to a PC.

Operating modes and key features

• Monitoring – real-time monitoring applications; logger sends measurements to PC in real time and buffers measurements when communication is interrupted.
• Recording / Playback – recorder logs measurements in internal memory for later download to PC.
• IP65 aluminium enclosure (probe excluded).
• Includes ½ wave antenna and SMA RF connector.
• Power supply: AA Lithium Thionyl battery (included) with plug-in connector.
• ILS functions: wakeup from hibernate mode; trigger a measurement outside the set measurement frequency.

Additional physical/operational details
The product is dew-formation resistant and the maximum dew point is reduced to 80°C. RF communication range in open terrain is typically 100 m to 1 km depending on the reception antenna. Time resolution is 1 s and data memory retention is specified up to 100 years.

Technical specifications

• Model designation: LGR64 (LGR64-001)
• Temperature measurement range: -40°C … +85°C
• Relative humidity measurement range: 0 … 100 % RH (maximum dew point reduced to 80°C; dew formation resistant)
• Temperature accuracy: ±0.2°C
• Humidity accuracy: ±1.8%
• Resolution: Humidity: 0.03 %RH; Temperature: 0.015 °C
• Response time (temperature & humidity): < 10 s
• Long term drift: Humidity < 0.5 %RH / year; Temperature < 0.05 K / year
• IP rating: IP65 (sensor excluded). Tightness valid only if probe and antenna seals are properly tightened.
• Battery: AA Lithium Thionyl (included) with plug-in connector
• Autonomy at 25°C: Up to 3 years (with measurements every 10 minutes; average value depending on use; given with product operating in non-alarm mode)
• Antenna RF connector: SMA connector
• Antenna supplied: ½ wave antenna (included)
• RF range (open terrain): 100 m to 1 km (depending on reception antenna)
• Memory capacity: 32 256 measurements with date and time
• Time resolution: 1 s
• Time deviation: ±2 min / month at 25°C
• Data memory retention: 100 years
• ILS integrated functions: wakeup from hibernate; trigger measurement outside frequency interval
