Single-axis inclinometer ASC TSF-360-CANCANCANopenMEMS
Add to favorites
Compare this product
Characteristics
- Number of axes
- single-axis
- Output
- CAN, CANopen
- Technology
- MEMS
- Other characteristics
- high-resolution, agriculture, for solar trackers, high-precision, for the construction industry, IP67, with aluminum housing
- Inclination
Max.: 360 °
Min.: 0 °
- Resolution
0.01 °
Description
Product overview
Technology
The ASC TSF is based on proven MEMS technology with a fluidic operating principle. The integrated electronics accept a supply voltage from 9 to 36 VDC. Analog measurement signals are digitized internally and transmitted via the CAN/CANopen interface. Thanks to internal compensation the uniaxial tilt sensor provides accuracy < 0.15° over the full 360° range and a temperature range from -40 °C to +85 °C, with a resolution of 0.01°.
Housing
The tilt sensors use a robust aluminum housing with protection class IP67 and a standard 5-pin M12 CAN connector.
Applications
Easy integration makes the tilt sensors particularly suitable for system monitoring of cranes and construction machinery, orientation of solar collectors and for agricultural vehicles in the field.
Technical specifications
- Sensor type: Digital tilt sensor
- Sensor technology: MEMS fluidic
- Number of sensitive directions: Uniaxial
- Output signal: CAN/CANopen
- Measurement range [°]: 360
Technology
The ASC TSF is based on proven MEMS technology with a fluidic operating principle. The integrated electronics accept a supply voltage from 9 to 36 VDC. Analog measurement signals are digitized internally and transmitted via the CAN/CANopen interface. Thanks to internal compensation the uniaxial tilt sensor provides accuracy < 0.15° over the full 360° range and a temperature range from -40 °C to +85 °C, with a resolution of 0.01°.
Housing
The tilt sensors use a robust aluminum housing with protection class IP67 and a standard 5-pin M12 CAN connector.
Applications
Easy integration makes the tilt sensors particularly suitable for system monitoring of cranes and construction machinery, orientation of solar collectors and for agricultural vehicles in the field.
Technical specifications
- Model: ASC TSF-360-CAN
- Sensor technology: MEMS fluidic
- Number of sensitive directions: Uniaxial
- Measurement range: 360°
- Output signal / Interface: CAN / CANopen
- Accuracy: < 0.15° (over full 360° range, with internal compensation)
- Resolution: 0.01°
- Power supply: 9 to 36 VDC
- Temperature range: -40 °C to +85 °C
- Protection class: IP67
- Housing material: Aluminum
- Connector: Standard 5-pin M12 CAN connector
- Internal signal processing: Analog measurement digitized internally
