Paint preparation machine 3-22 series

Overview The C.A.R.FIT Fast Paint System (FPS) is a paint preparation system for mixing, filling and temporary storage of coatings. It is designed to simplify clean preparation workflows and to reduce time and material waste.

Use FPS is compatible with all spray gun types when used with the appropriate adapters. The system also enables temporary storage and later reuse of leftover paint to optimize consumption.

Contents / Available items

• Item no.: 3-225-0002/0200/0400/0850 — 1 hard cup, 1 collar; mixing cup capacities: 200, 400, 605, 850 ml
• Item no.: 3-225-0125/2125/4125/8125 — 25 inner cups, 25 lids, 12 caps; 125 microns; capacities: 200, 400, 650, 850 ml
• Item no.: 3-225-0190/2190/4190/8190 — 25 inner cups, 25 lids, 12 caps; 190 microns; capacities: 200, 400, 650, 850 ml

Adapters

• Item no.: 3-226-0001 — Fast Paint System adapter for W400/W400LV/WR400/LPH400
• Item no.: 3-226-0002 — Fast Paint System adapter for Sagola 4100 GTO
• Item no.: 3-226-0003 — Fast Paint System adapter for Devilbiss GTI
• Item no.: 3-226-0004 — Fast Paint System adapter for SATA QCC
• Item no.: 3-226-0005 — Fast Paint System adapter for IWATA Supernova WS400/LS400
• Item no.: 3-226-0006 — Fast Paint System adapter for IWATA LPH-80mini

Downloads Technical data sheet available for this product.

Additional information All components are corrosion-resistant to paint and thinner. Black liner and lid provide UV resistance for improved storage stability.

Melting point / Temperature Lid & outer cup melting point: 170℃; liner melting point: 120℃; maximum working temperature: 80℃.

Technical specifications

• Brand: C.A.R.FIT
• Product type: Paint preparation system for mixing, filling and temporary storage
• Compatibility: Suitable for all spray gun types with specific adapters (see adapters list)
• Available cup capacities: 200 ml, 400 ml, 605 ml, 650 ml, 850 ml
• Packaging / kits: single hard cup kits and multi-pack inner cup/lid sets (25 pcs) with caps
• Filter / micron options: 125 μm and 190 μm
• Material resistance: corrosion-resistant against paint and thinner
• UV resistance: black liner and lid are UV-resistant
• Thermal limits: lid & outer cup melting point 170℃; liner melting point 120℃; max working temperature 80℃
• Relevant item numbers: 3-225-0002/0200/0400/0850; 3-225-0125/2125/4125/8125; 3-225-0190/2190/4190/8190; adapters 3-226-0001 to 3-226-0006
