Digital pyrometer BL612

°CRS4854-20 mA

Spot pyrometers are a type of fixed thermal sensor used for measuring a single point on high-temperature surfaces, often in large furnaces or kilns. These devices measure temperature from the thermal radiation emitted, also known as radiometry. The BL612 spot pyrometers are fast and high-precision instruments that combine the versatility and benefits of digital signal processing. The temperature measurements of metals and ceramics is from 100°C to 3000°C with adjustable focus. The 1.6um and 2.3um shortwave spectral ranges is for measurements on metals, shiny materials, ceramics, graphite andmany more. FEATURES Single color, two color and fiber opticoptions Temperature measuring ranges from 100 – 800°C to 400 -3000 °C Manual focusing measured distances from0.5m Superior optical resolution to 300:1 Easy adjustment with manual variablefocuses integrated head optics Sighting options: through-the-lens sighting, with optional laser, LED or video aiming function Compact, rugged steel housing with IP65rating Programmable relay output for control APPLICATION 1.6 µm nominal single color: Ferrous, non-ferrous and unoxidized metals, galvanizing lines & steel annealing, small targets such as in wire coating & annealing, plastic tubing extrusions 2.3 µm nominal single color: Ferrous, non-ferrous and unoxidized metals, galvanizing lines & steel annealing
