LED display 806

LCDbar graphinformation

Limited space in your cockpit? The casing of the all round solution has just a cutout of 52 mm, but supplies maximum 3 LEDs and a backlit LCD. The 6 digit indication visualises for instance: Operating hours, service values and on the 10 segment bar graph you can find the information about the battery discharge level, fuel level or vehicle temperature. Optionally 2 buttons can be integrated. The 3 alert lamps inform you of disturbances or limiting values. Casing: Material: plastic PC-ABS, colour black Front side: chemical and UV resistant polyester foil Viewing area: polycarbonate glass LCD: 1x 10 bar graph segments for battery discharge level 6x 7 segment indication for the following functions: 1. Operating hours (maximum 99999,9h), 2. Service hours (maximum 9999h), 3. Battery discharge level (%), 4. Error codes Backlit: green-yellow LED indication: Maximum 3 LEDs Inputs: CAN Bus interface Supply voltage: 8…28 VDC Current consumption: Maximum 80 mA @ 12 VDC Ambient temperature: -40° C…+80° C Storage: -40° C…+80° C Electrical connections: AMP-Tyco Mini-Universal-Mate-N-Lok splash proof sealed, 10 pole Fixing: Metal clamp with 2 screws Protection class: IP65 front, IP40 on the rear Vibration resistance: EN 60068-2-64, SAE J1378 EN 60068-2-64, SAE J1378 EN 60068-2-27, EN 60068-2-29, SAE J1378 EMC: EN 12895, EN 40839-1, DIN 13309 Approval: CE
