AC servomotor AM8721
400 V480 V100 V

AC servomotor - AM8721 - Beckhoff Automation - 400 V / 480 V / 100 V
AC servomotor - AM8721 - Beckhoff Automation - 400 V / 480 V / 100 V
Add to favorites
Compare this product

Characteristics

Type
AC
Voltage
400 V, 480 V, 100 V
Applications
food, for the pharmaceutical industry, for the chemical industry
Other characteristics
performance
Power

0.42 W
(0 hp)

Intensity

0.85 A, 4.9 A

Torque

0.5 Nm, 2.68 Nm
(0.368781 ft.lb, 1.976667 ft.lb)

Diameter

77 mm
(3.03 in)

Operating temperature

Min.: 5 °C
(41 °F)

Max.: 40 °C
(104 °F)

Description

The servomotor AM8721 with anodized housing is designed for applications in food, pharmaceutical and chemical industries. It is suitable for drive solutions with highest demands on dynamics and performance in the 100…480 V AC voltage range. The motor is equipped with an OCT direct cable outlet and the standstill torque is 0.50 Nm. The servomotor with flange code R2 (77 mm) and motor length 1 has a shaft diameter b=9 k6 and a free shaft end of d=20 mm.
