Turnstile with badge reader TF1000-Evo

anti-fraudtripodthree-arm

Short description
The TF1000-Evo turnstile controls pedestrian access in both directions for outdoor installations. Its presence-control system verifies actual user passage and restricts access to a single person per lane.

Applications

• Industrial sites
• Service and office buildings
• Banking facilities
• Nuclear sites
• Data centres
• Prisons and detention centres
• Airports and transport hubs

Operation
On authorization from the access control system, the rotor rotates in the requested direction with a slight manual push. The reduced passage width prevents more than one person entering the secured area per lane.

Design
The TF1000-Evo is manufactured in thermolacquered steel and fitted with a protective canopy featuring an integrated gutter for rainwater evacuation. It has an IP54 rating. Provision is available to integrate badge readers, configurable for entry and exit. The unit includes Blue Energy standby lighting and a head-level red/green signalling. The rotor and comb are sealed and highly durable; arms are oblong with 30/60 mm diameters.

Customization
Multiple structure colours available (green, black, grey) and configurable badge-reader positions.

Safety
Drive is provided by two electromagnets controlled by a programmable logic controller. Positions are mechanically locked by reinforced steel bolts. The assembly includes an adjustable hydraulic torque damper and an anti-crossing system to limit reverse-entry attempts.

Options
Available options include two-person passage detection, effective passage detection, indirect under-canopy lighting and a mechanical passage reducer for increased security.

Technical specifications

• Model: TF1000-Evo
• Brand: Bolloré
• Type: Turnstile (pedestrian access control, two-way, outdoor)
• Passage width: 680 mm
• Total height: 2060 mm
• Throughput: 10–12 people per minute
• Material: thermolacquered steel
• Ingress protection: IP54
• Rotor and comb: sealed and durable
• Arms: oblong, diameter 30/60 mm
• Lighting: Blue Energy standby; head-level green/red signalling
• Badge reader integration: provision provided (configurable entry/exit)
• Drive: two electromagnets controlled by PLC
• Locking: reinforced steel bolts
• Damper: adjustable hydraulic torque damper
• Anti-crossing system: yes
• Outdoor installation: yes
• Country of design/manufacture: France
