2-axis linear module 700

Add to favorites

Compare this product

Characteristics

Number of axes

2-axis

Linear speed

Max.: 80,000 mm/min

Min.: 0 mm/min
(0 in/s)

700 Electronic pusher module - Twin axis

The twin-axis concept enables smooth, precise handling of unstable containers at high line speeds
Retrofittable via a special adapter plate to most existing conveyors
Graphic ramp-profile simulation supports fine tuning of handling parameters

High-speed twin-axis servo pusher

Machine conveyor

Basic UBC conveyor available for up to 12 sections single-bed or up to 24 sections tandem machines
Air-cooling inlets configurable at front or rear of conveyor body
Optional Separate Belt Cooling: two different air pressure levels on beam and dead plate for greater cooling flexibility
Optional Independent Cavity Cooling: individual control of inner and outer cavity on dead plate for improved cooling equalization

700 Electronic pusher module features

Advanced diagnostics: alarms, event modification log, system and motor status, real-time production data
Mechanical group reversible: left or right delivery without additional parts
Quick-change single-motor pusher mechanism for reduced maintenance time

Technical specifications

Twin-axis concept for precise handling of unstable containers at high speed
Retrofittable via special adapter plate to most existing conveyors
Graphic ramp-profile simulation for handling fine tuning
Suitable for IS 12 sections TG and tandem machines
Machine conveyor speed: up to 80 m/min
Maximum article diameter: 75 mm (TG 4-1/4”)
Basic UBC conveyor: up to 12 sections single-bed or up to 24 sections tandem
Air-cooling inlets: front or rear of conveyor body
Optional Separate Belt Cooling: two air-pressure levels on beam and dead plate
Optional Independent Cavity Cooling: individual inner/outer cavity control on dead plate
Advanced diagnostics and real-time production data
Reversibility of delivery direction without extra parts
Quick-change single-motor pusher mechanism
