Safety relay MXC-20

voltagecurrentSPDT

Single phase current relay for detecting a level of AC or DC current. When the monitored current rises and reaches the determined setpoint, which is adjusted on the front panel, the relay energises. When the current drops and passes the setpoint, minus the hysteresis which is adjustable on the front, the relay de-energises. With inverted relay function the internal relay work the opposite way. The Current Relay has a latch function where the relay after energising will remain energised, regardless of input current, until the latch jumper or the operating current is disconnected. Typically used in safety circuits. Features • Monitoring of 10mA - 5A AC/DC in 5 ranges. • Adjustable setpoint. • Adjustable hysteresis 3-35%. • Automatic locking function (Latch). • Inversion of the relay function. • Output SPDT. • Operating voltage 24VDC , 24VAC, 115VAC, 230VAC or 400VAC.
