Condition monitoring system VIBROCONTROL 950/960

vibrationfor machine protectionalarm

Effective vibration monitoring of semi-critical machinery. VIBROCONTROL 950/960 are single-channel online vibration monitoring devices. They effectively protect machines with rolling-element bearings from damages caused by e.g. unbalance or misalignment which can be detected by analyzing the vibration patterns. The instruments are ideally suitable for monitoring balance-of-plant machinery, e.g. fans, blowers, pumps, decanters, separators and mills. For monitoring critical and high-speed machinery, please refer to our VC-8000 machinery protection system. VIBROCONTROL 950 works with constant-current sourced accelerometers; VIBROCONTROL 960 uses velocity sensors to capture the vibration data. Both instruments are mounted on a DIN rail in machine cabinets. A field housing is available as an option. Both instruments come with a user software for easy and flexible set-up. • Input of accelerometers (CCS): VIBROCONTROL 950 • Input of velocity sensors: VIBROCONTROL 960 • 2 relays (Alarm & Danger) and 1 OK relay • Analog output • Large integrated display • Vibration levels in realtime • Installation: DIN Rail mounting or optional field housing • Power supply +24 VDC • Machine protection according to DIN/ISO 10816-3 • Software: Compact Setup
