Rotary blade cutting center BAZ 3000for stoneblocksCNC
Add to favorites
Compare this product
Characteristics
- Technology
- rotary blade
- Material
- for stone
- Product handled
- blocks
- Control type
- CNC
- Associated function
- surfacing, polishing
- Applications
- for industrial applications
- Configuration
- bridge, 5-axis, 6-axis, 3-axis, 4-axis
- Other characteristics
- precision, vertical
Description
The CNC work center with 3 to 6 interpolated axes guarantees a maximum of precision and flexibility. A newly-developed electronic and pneumatic pressure regulation makes perfect surfacing and polishing possible. Easy handling and well-developed software ensures trouble-free and economical operation.
Technical data
Saw blade diameter: - 400–1000 mm
Cutting depth: - max. 350 mm
Electro spindle: - 25–37 kW
Speed range: - 500–8000 U/min
Spindle carriage travel: - 3900 mm
Bridge travel: - 3000–10.000 mm
Vertical travel: - 1200–1500 mm
