Digital power supply unit SY8800

analog

Factory configured modular system 5 free slots for power supply modules 3U x 19″ x 35 cm crate size Floating channels Local and Remote Control Remote control via Ethernet, USB, CANBUS and RS232 Max output power: 2.5kW @ 220Vac, 1.5kW @ 115Vac Up to 8 independent channels Low noise Avalaible Modules: 2÷7V 550W (110A@5V) 1 slot 2÷7V 1100W (220A@5V) 2 slot ±7÷16V 550W (23A@±12V) 1 slot ±7÷16V 1100W (46A@±12V) 2 slot ±20÷28V 550W (11A@±24V) 1 slot ±20÷28V 1100W (22A @±24V) 2 slot 10 mV Voltage Set/Monitor resolution 100/200 mA Current Set/Monitor resolution (2÷7V) 20/40mA Current Set/Monitor resolution (±7÷16V/±20÷28V) Individual channel ON/OFF and TRIP Sense wires for the voltage drop recovery 4 Analog Input, 4 Digital Input, 4 Digital Output Fans embedded for vertical cooling Overview The Mod. SY8800 is a high density floating low voltage power supply system, designed to power low noise electronics with medium and high currents. Six modules have been developed so far: 2÷7V 550W (typ. 110A@5V) 2÷7V 1100W (typ. 220A@5V) ±7÷16V 550W (typ. 23A @±12V) ±7÷16V 1100W (typ. 46A @±12V) ±20÷28V 550W (typ. 11A@± 24V) ±20÷28V 1100W (typ. 22A@± 24V) The system is factory-configured. The system is provided with Remote Sensing Lines to compensate for the voltage drop over the connection cables. Safety features include: Overvoltage and Undervoltage protection when the output voltage differs from the programmed value Programmable maximum channel output voltage limit (VOVP): the channel is tripped off when its output voltage exceeds VOVP
