Combination road roller DV209D

Overview
The CASE DV209D is a double-drum vibratory roller engineered for heavy compaction tasks on roads, sites and base layers. It delivers 100 hp (74.4 kW) and centrifugal forces to the ground of up to nearly 19,000 lb, combining power with controllable vibration modes for consistent compaction performance.

Quick specifications

• Horsepower: 100 hp | 74.4 kW
• Operating weight: 21,080 lb | 9 560 kg
• Centrifugal force: up to nearly 19,000 lb

Standard equipment
Other

• Fixed ROPS/FOPS canopy
• Deutz TCD 3.6 L4 / Tier 4 Final engine
• Drum offset with crab steer capability
• Vucollon fixed drum scrapers
• Worklights with integrated turn signals

Operator environment

• Rubber-mounted operator platform
• 4-way adjustable rotating seat and lateral moving suspension seat with foldable arms
• Smooth start and stop; single lever speed and direction control with vibration on/off

Monitor display panel

• Steering wheel display relays engine load at current RPM and key operational data

Water system

• Pressurized water system with multi-stage filtration (triple/2-stage references)
• Dual fill port tank, adjustable sprinkler volume control, water system on/off and drains

Vibration system

• Front, rear and dual drum vibration control modes
• Dual-mode vibratory system with auto vibration stop in neutral

Telematics

• myCASEConstruction hardware included with 7-year advanced data subscription

Optional equipment
Other

• Right side edge cutter (45° or 60°)
• Right and left side edge cutters (45° or 60°)
• Tiltable scrapers — front and rear
• Infrared thermometer
• ACE Force intelligent compaction

Warranty

• 1-Year / Unlimited-Hour full-coverage base limited warranty
• 2-Year / 2,000-Hour extended limited engine warranty
• Purchased Protection Plan available up to 6 years / 7,500 hours on CASE compaction equipment

Technical specifications

• Model: DV209D
• Engine: Deutz TCD 3.6 L4 / Tier 4 Final
• Power: 100 hp | 74.4 kW
• Operating weight: 21,080 lb | 9 560 kg
• Centrifugal force (output to ground): up to nearly 19,000 lb
• Water system: pressurized; multi-stage filtration; dual fill port; adjustable sprinkler control; drains; on/off
• Operator platform: rubber-mounted; adjustable rotating seat; lateral suspension with foldable arms
• Steering wheel display: engine load and operational info
• Drum: offset (crab steer); Vucollon fixed scrapers
• Vibration: front, rear and dual drum modes; dual-mode system; auto stop in neutral
• Lighting: worklights with turn signals
• Telematics: myCASEConstruction hardware + 7-year advanced data subscription
