Thyristors power controller REVO E

SCRdigitalthree-phase

REVO E 3PH Thyristor Power Controller is for Inductive Loads, including Resistance, Kanthal Super (MoSi2 Element) or SiC element on Secondary of Transformer, an Universal and Digital Unit based on configurable powerfull microprocessor. It is possible to configure all inputs, the firing mode and control mode for all load type. SCR Power Controller suitable for most applications including Short Wave Infrared (SWIR) & Inductive load types Current range – 35A, 45A, 75A, 100A, 125A, 150A, 225, 300A, 350A, 400A, 450A, 500A Three leg switching of 3/4 wire star or 3/6 wire delta loads Fully digital and user configurable for all inputs, firing modes, feedback modes and load types Firing modes include zero crossing (ZC), burst firing (BF), single cycle (SC), soft start + burst firing (S+BF) and phase angle + soft start (S+PA) Microprocessor based electronic circuit fully isolated from power Universal input signal with automatic zero/span calibration Power feedback or voltage compensation RS485 Comms MODBUS protocol as standardUnbalanced loadHeater break alarm to diagnose partial or total load failure and short circuit Control & monitor power, current & voltage via external keypad (CD-KP) IP20 Protection
