Fixed scaffolding MULTICETA

modularfacade

MULTICETA MULTIDIRECTIONAL SCAFFOLDING SYSTEM The scaffolding system in hot-dip galvanised steel with the multidirectional rosette is suitable for all types of construction. Width 77 cm – Modules 44-50-77-100-110-150-180-200-250-300 Width 110 cm – Modules 44-50-77-100-110-150-180-200-250 MULTICETA MULTIDIRECTIONAL SCAFFOLDING System With cross-braces and cross-beams, with an 8-way multidirectional rosette MaterialS235JR, S355JR steel TubesDiameter 48.3 mm Nominal thickness 3.2 mm FinishHot-dip galvanised coating in accordance with UNI EN ISO 1461 WeldingIn accordance with regulations UNI EN ISO 15607 and UNI EN 1418 Ministerial authorisationFor loads of 300 N/m2 EN 12811 CertificationCertificate of conformity of the scaffolding to European regulations EN 12810-1 and EN 12811-1 MC SYSTEM WIDTH 77 CM DIMENSIONS Width77 cm Bay length44 / 50 / 77 / 100 /110 / 150 / 180 / 200 / 250 / 300 cm Height200 cm MC SYSTEM WIDTH 110 CM DIMENSIONS Width110 cm Bay length44 / 50 / 77 / 100 /110 / 150 / 180 / 200 / 250 cm Height200 cm Fields of application: Residential Industrial Restoration Petroleum Naval Aeronautics Archaeological sites Entertainment Bridges Viaducts
