Analog ammeter CP-C series

AC/DCpanel-mountpower distribution

CP-C moving coil panel meter with sprung toe bearing is insensitive to external magnetic fields. The movable organs of the movements are stored in sprung jewels in order to protect them against crushes and vibrations. These oving coil panel meters only measure DC current or DC voltage. By using core magnets of high quality the moving coil, the CP-C moving coil panel meter has a almost linear scale course. Due to their low consumption they are especially suited for the application with shunts, impulse transmitters, thermo couples and for the connection to our electronic transducers. The instruments can be delivered for direct connection up to 100 A with a built-in shunt. • M4 screw connections with clamps make this easier Clamping the connecting wires. • Housing use matiral match UL94V-0 standard • All fastenings suitable for shaking and shock resistance. • Accept special customization requirements Ordering info of CP-C Panel Meter Moving Coil Measurement range (Include CT/VT ratio) Overload (Amp/voltage reading) Accuracy class Operation frequency Marine use or not Need rectifier AUX or not (model code [C]–>[L])
