Compact current rectifier SET-X series

DCswitchingrack-mount

SET-X Modular Rectifier uses an advanced modular design, with multiple rectifier modules together in one 19” rack box. This modular design of this rectifier battery charger makes it flexible to provide enough power supply for Telecom and Power Industrial equipment use. The battery charger rectifier’s power output can be adjusted by adding or removing rectifier modules. It supplies a steady DC output for regular loads, float charging, and equalized charging. The DC rectifier system adjusts automatically based on the load requirements, reflecting customers’ purchasing habits and thought processes. • PFC + DC/DC transformation supports a wide input voltage range (85V-290V) • Hot-swapping, plug-and-play, redundancy with N +1 configuration, and expansion slots. • 2U-6U height, lightweight, High power density. • High efficiency, efficiency can be 91% at 10% low power load rate condition, 96% at 50% load rate. • With stepless current limiter technology, the output current can be continuously adjustable. • Adopted step-less temperature control speed, reduce power consumption and expand the working life of the fan. • Monitor battery voltage and charge/discharge current in real-time, with automatic control for boosting and floating charging. • Automatic load sharing, equalized-current imbalance < 3% • Collect digital signals using an internal RS485 bus and allow for remote operation through an RS232 interface. • Optional Ethernet interface through SNMP and/or TCP/IP
