Heavy series handling rollers mainly used for the transportation of heavy goods.
CP-101M / LH
• Ø80×3, Ø89×3, Ø108×3.6 and Ø133×4 metal tubes made of natural, zinc-plated or AISI 304 stainless steel.
Ø20, Ø25 and Ø30 metal shafts in calibrated natural steel F212 or AISI 303 stainless steel.
Z10 1 ”single metal sprocket, in natural, zinc-plated or AISI 303 stainless steel.
Welded metal cup with 6000 2RS series precision bearings plus labyrinth seal.
Maximum load capacity 250 Kg / roll.
CP-1358M / M44-LH
• Ø80×3, Ø89×3 and Ø108×3.6 metal tubes in natural, zinc-plated or AISI 304 stainless steel.
• Transmission through 5/8 ”, ¾” and 1 ”chain pitch sprockets.
• Ø17, Ø20 and Ø25 metal shafts in calibrated natural steel F212 or AISI 303 stainless steel.
• Single or double Z13 5/8 ”metal sprocket, in natural, zinc-plated or AISI 303 stainless steel.
• Zinc plated metal head with embedded 6000 series 2RS precision bearing, or welded metal cup with 6000 2RS series precision bearings plus labyrinth seal.
CP-1534M / M44-LH
• Ø80×3, Ø89×3, Ø108×3.6 and Ø133×4 metal tubes made of natural, zinc-plated or AISI 304 stainless steel.
• Ø20, Ø25 and Ø30 metal shafts in calibrated natural steel F212 or AISI 303 stainless steel.
• Z15 3/4 ”single or double metal sprocket, in natural, zinc plated or AISI 303 stainless steel.
• Zinc plated metal head with embedded 6000 series 2RS precision bearing, or welded metal cup with 6000 2RS series precision bearings plus labyrinth seal.
CP-1558M / M44-LH
• Ø80×3, Ø89×3, Ø108×3.6 and Ø133×4 metal tubes made of natural, zinc-plated or AISI 304 stainless steel.
• Transmission through 5/8 ”, ¾” and 1 ”chain pitch sprockets.
