Safety relay MS2A31-0243 NO1 NCDIN rail
Add to favorites
Compare this product
Characteristics
- Measured/monitored value
- safety
- Contact configuration
- 3 NO, 1 NC
- Mounting
- DIN rail
- Norms
- SIL
- Trigger voltage
24 V
Description
Safety module – Suitable for control of limit switches for safety gates, safety magnetic sensors, emergency stops and electro-sensitive protection devices ESPE
3 safety NO OSSD outputs + 1 signalling NC OSSD output
2 channel configuration for safety systems up to SIL 3 (according to EN62061) and PL e (according to EN ISO 13849-1)
MANUAL START or AUTOMATIC START configuration
Plastic casing – IP20
