Static mixer Intermixer

side-mountcontinuousin-line

Overview
The TPBX007-0824 Material Mixer mounts between the processing machine throat and the material supply to provide continuous in-line mixing of resins, colorants and additives. It is compatible with Conair throat feeders, material hoppers and vacuum loaders for an integrated feeding and mixing solution. The unit features a removable plexiglass front cover for visual inspection and easy access for cleaning, and is available with 6 or 8 inch mounting flanges in inline or offset configurations.

Key features

• Tool-free cleaning: Smooth interior chamber prevents material build-up and quick-release latches allow fast access to the mixing chamber.
• Feeder compatibility: Designed to match Conair BF and BFH series color feeders for seamless integration.
• Continuous mixing: Maintains a consistent blend to the process machine during throat feeding of colorants and additives.
• Visual inspection: Removable plexiglass front cover enables monitoring of mixing action and simplifies maintenance.
• Flexible installation: Available inline or offset; mounts directly between machine throat and material supply with 6 or 8 in flanges.

Applications

• Extrusion, injection molding and other thermoplastic processing where consistent color/additive distribution is required.
• Processes using throat feeding of colorants, regrind or additives to maintain uniform material properties.

Installation & compatibility
Installs between the processing machine throat and the material supply. Can be combined with Conair throat feeders, material hoppers and vacuum loaders. Choose 6 or 8 in mounting flanges and inline or offset configuration to suit machine throat dimensions and factory layout.

Specifications

• Mounting: 6 or 8 inch mounting flanges
• Construction: compact, industrial-grade design
• Cover: removable plexiglass front cover for visual inspection and easy clean out
• Chamber: smooth surface chamber body to prevent material trapping
• Access: quick-release latches for tool-free cleaning
• Compatibility: matches Conair BF and BFH series feeders; compatible with Conair throat feeder, material hopper and vacuum loader
• Mixing: continuous mixing for consistent blends; suitable for throat feeding colorants and additives
• Installation: mounts between processing machine throat and material supply; available in inline or offset configurations

Resources
Manufacturer catalog and full specification sheet (TPBX007-0824 Material Mixer) available on request.
