GSM communication module GW-42

GPRSDIN rail

GW-42 is an industrial DIN rail GSM modem for the supervision and control of remote inputs and outputs by means of enhanced features available through GSM network and the Web. GW-42 sends user defined messages via SMS, e-mail or free phone rings. GW-42 can provide detailed reports on input status and notify local events. Outputs can be controlled by authorized users via SMS, Web, free phone rings and phone keyboard. The user can configure the unit to deploy actions when a specific event occurs. CONTROL • SMS multiple commands, case insensitive • SMS timer and schedule commands • CLIP (pulse, toggle and reverse mode) • DTMF (multiple keyboard commands) REPORTS / ALARMS • SMS, Status SMS (specific for each recipient) • Phone call • Email (specific for each recipient)) SPECIAL FEATURES • Local and remote configuration • LOG tracing to com port • LOG memory (last 99 activities) • Real time clock (autosync) • Scheduled activities • Users management
