Iron core linear motors are best suited for applications involving high-acceleration, -velocity and -load point-to-point linear motions. High Force Density The iron core linear motors feature high force output through strong magnetic coupling between the iron core and the stator magnets. Easy Heat Dissipation The iron core itself helps transfer the heat generated in the coils during operation, thereby facilitating heat dissipation to the ambient. dot Easy Assembly The iron core linear motors can be readily assembled, with the forcer and the stator directly facing each other. In a linear motor system, the slider. linear guide and base are ail paths of heat dissipation for the coil. Similarty. cooling effects are also achieved by the natural air flow over the motor while it is in motion. The thermograph image on the right shows the overall linear motor system temperature distribution afterreaching thermal equilibrium. It is obvious from this that the heat from the coi is dissipated through everything it is in contact with. To ease estimation of the required heat sinking capacity,
