Gas detector UnoIQ

chlorineammoniamethane

Product overview
The UNOIQ is a personal, rechargeable single-gas detector with modular, field-serviceable sensor trays and optional wireless connectivity. Designed for demanding industrial environments, it supports live data, device configuration and asset management via the Crowcon Connect cloud platform.

Key features

• Personal, rechargeable single-gas detector
• Modular, serviceable sensor trays: plug-and-play pre-calibrated trays that can be swapped without manufacturer intervention
• Extended battery life with fast recharge (0–80% in ~2 hours; 0–100% <3 hours)
• Seamless hub integration (IQhub) for automated bump testing (<10 s), calibration (<30 s), configuration and compliance reporting
• Multiple alarm methods: visual, vibrating and audible (95 dB); supports low/high, TWA and STEL
• Compact, lightweight design with one-button operation
• Upgradeable to dual-gas detection

Modular sensor tray benefits

• Swap pre-calibrated sensor trays in the field without returning the device to the manufacturer
• Reduce downtime and maintenance costs
• Plug-and-play flexibility to target different gases

Extended battery life

• Up to one month between charges depending on sensor and usage (e.g., 31 days for O2 on 8-hour shifts)
• Quick recharge: 0–80% in ~2 hours; 0–100% <3 hours

Seamless hub integration

• Dock-and-go operation with IQhub
• Automated bump tests (<10 s) and calibrations (<30 s)
• Compliance reporting and simple asset management

Gases and ranges
Ammonia (NH3): 0–100 ppm, resolution 0.1 ppm
Butane (C4H10): 0–100% LEL, resolution 1% LEL
Carbon Dioxide (CO2) (Non-IS): 0–2% vol., resolution 0.01% vol.
Carbon Monoxide (CO): 0–250 ppm, resolution 1 ppm
Chlorine (Cl2): 0–10 ppm, resolution 0.1 ppm
Hydrogen Sulphide (H2S): 0–100 ppm, resolution 0.1 ppm
Methane (CH4): 0–100% LEL, resolution 1% LEL
Nitrogen Dioxide (NO2): 0–20 ppm, resolution 0.1 ppm
Oxygen (O2): 0–25% vol., resolution 0.1% vol.
Ozone (O3): 0–1 ppm, resolution 0.1 ppm
Sulphur Dioxide (SO2): 0–20 ppm, resolution 0.1 ppm

Connectivity and sensors

• NFC and optional Bluetooth® for connection to Crowcon Connect (live data, configuration, reporting)
• Sensors available: electrochemical, IR, pellistor and long-life O2
• Event logging: up to 500 event logs

Technical specifications

• Dimensions (standard): 96 x 55 x 32 mm; deep tray: 106 x 55 x 32 mm
• Weight: 134.2 g (varies by configuration)
• Durability: 6 m drop test
• Response time (T90): <10 s (sensor dependent)
• Sampling: diffusion (no pump)
• Operating temperature: −20 to +55°C (−4 to +131°F)
• Humidity: 0–95% RH
• Ingress protection: IP66 and IP68
• Approvals: CSA US Class I, Division 1, Groups A,B,C,D T4*; ATEX Ex II 1G Ex ia IIC T4 Ga; IECEx Ex ia da IIC T4 Ga; INMETRO Ex ia IIC T4 Ga*; RED/FCC/IC for wireless (*some approvals pending)
• Calibration and maintenance: automated bump testing (<10 s) and calibration (<30 s) via IQhub; manual bump/calibration via device and PC software
• Accessories (examples): USB-A and USB-C power cable, Flowplate, IQhub, Klick Fast mounts and docks
• Warranty: 2 years (sensor warranty separate)
