Mini-excavator DX19-7

crawlerdieselconstruction

Overview
The DX19-7 is a compact mini excavator designed for construction tasks that require stability, lift capacity and maneuverability. Its retractable undercarriage and optimized breakout forces enable operation in confined spaces while handling a wide range of attachments.

Product summary
Powered by a Kubota D902 engine delivering 12.1 kW (16.5 hp) @ 2400 rpm, the DX19-7 combines fast cycle times with increased lifting capability and extended reach to improve on-site productivity. The machine balances compact dimensions with working performance for diverse construction applications.

Key benefits

• Optimized stability and increased lifting capacity for versatile attachment use
• Retractable undercarriage for access to tight spaces
• Proportional auxiliary flow for smooth, powerful attachment operation
• Clear all-round visibility and ergonomic operator environment
• Spacious canopy with ISO-certified TOPS/ROPS/FOPS protection
• Sensitive joysticks with reduced noise and vibration for operator comfort

Specifications
Operating weight: 1885 kg
Engine power: 12.1 kW (16.5 hp) @ 2400 rpm
Bucket capacity: 0.04 m3
Max. digging depth (std / long arm): 2340 / 2540 mm
Max. reach at ground level (std / long arm): 3850 / 4040 mm
Digging height: 3585 mm
Digging force (bucket, ISO): 14.1 kN
Digging force (arm, ISO): 8.8 kN
Boom swing (L/R): 55°/59°
Rear swing radius: 1760 mm
Track shoe width: 230 mm
Travel speed (low / high): 2.06 / 3.73 km/h
Hydraulic flow: 34.6 l/min
Width (retracted / extended): 994 / 1290 mm
Engine model: Kubota D902

Options & Attachments

• Hydraulic breakers (HB series)
• Quick coupler bucket sets

Technical specifications

• Operating weight: 1885 kg
• Engine: Kubota D902
• Engine power: 12.1 kW (16.5 hp) @ 2400 rpm
• Bucket capacity: 0.04 m3
• Max. digging depth (std / long arm): 2340 / 2540 mm
• Max. reach at ground level (std / long arm): 3850 / 4040 mm
• Digging height: 3585 mm
• Digging force (bucket, ISO): 14.1 kN
• Digging force (arm, ISO): 8.8 kN
• Boom swing (L/R): 55° / 59°
• Rear swing radius: 1760 mm
• Track shoe width: 230 mm
• Travel speed (low / high): 2.06 km/h / 3.73 km/h
• Hydraulic flow: 34.6 l/min
• Width (retracted / extended): 994 / 1290 mm
• Canopy with ISO-certified TOPS/ROPS/FOPS
