Mini-excavator DX55R-7

trackedTier 4 - finaldiesel

Overview
The Develon DX55R-7 compact excavator is engineered for urban construction, utilities and landscaping. It pairs a Develon D18 engine (36.4 kW) with Stage V emissions compliance and a 5740 kg operating weight to deliver efficient fuel use and precise digging performance.

Cab & Comfort
Integrated heating and air-conditioning provide controlled cabin climate. An automatically controlled fan supplies pressurized, filtered air distributed through multiple vents. The operator seat features heated pneumatic suspension and a seat belt. Seat and joystick console are adjustable independently to suit operator preference.

Key machine highlights

• Compact footprint for confined-site work
• Stage V Develon D18 engine: 36.4 kW / 48.8 hp @ 2200 rpm
• Heated air-suspension operator seat and separately adjustable joystick console
• Optional hydraulic breakers and quick-coupler bucket sets

Specifications (key values)

• Operating weight: 5740 kg
• Bucket capacity: 0.16 m3
• Engine: Develon D18 (Stage V)
• Engine power: 36.4 kW / 48.8 hp @ 2200 rpm
• Maximum swing speed: 9.8 rpm
• Maximum swing torque: 1380 kgf·m
• Maximum traction: 4580 kg
• Maximum gradeability: 35° / 70%
• Width: 1980 mm
• Max. reach at ground level (standard/long arm): 5950 mm
• Max. digging depth (standard/long arm): 3630 / 3930 mm
