Web server DAT8024

DIN railEthernet

The DAT8024 module is a Modbus TCP server unit that can generate up to 4 analog output signals via digital commands. To the outputs it is possible to connect active or passive loop current up to 20 mA or voltage signals up to 10 V. The output channels are electrically isolated from each other. For each channel is provided an isolated power source for powering passive loop current. The device guarantees high accuracy and a stable measure versus time and temperature. In order to ensure the safety plant, the device is provided with a Watch-Dog Timer system. The Ethernet interface allows reading and writing in real time the values of the internal registers of the device. The LEDs of signalling of Ethernet activity and power supply allow a direct monitoring of the system functionality. The built-in Web Server of DAT8024 allows the remote visualization, setting of the analog outputs and the access to the main Ethernet programming parameters. The device is also configurable by the software Dev9K, a free IDE developed by DATEXEL.
