mixer-dispenser with gear pump / resin / two-component / high-precision
UNIDOS 300

Add to MyDirectIndustry favorites
Compare this product Don’t compare this product
mixer-dispenser with gear pump / resin / two-component / high-precision mixer-dispenser with gear pump / resin / two-component / high-precision - UNIDOS 300
{{requestButtons}}

Characteristics

  • Type:

    with gear pump

  • Applications:

    resin

  • Other characteristics:

    two-component, high-precision

Description

2-component metering- and mixing plant
For Applying: epoxy resins polyurethane resins silicones
Technical Data:
•Stainless steel chassis and working surface
•Rollers
•High precision steel gear pumps
•Three-phase current motor
•Various dispense rate at a mixing ratio of 100 : 100 available (1, 2, 4, 8,15 kg/min)
•Smooth adjustable mixing ratio
•Pressure lines 250 bar, free length 3.000 mm
•Re-circulation mixing block to machine container
•Mixing block with dynamic and static mixing
•Pneumatic mixer drive
•Disposable static mixers
•Purge of mixing block by use of one component and compressed air
•Trigger at mixing block
•Siemens controller
•Moisture trap
