Panel-mount indicator light D-7500

IP55AC/DC

Description
Series 7500 is designed for industrial environments, combining a compact panel mounting form factor with high-quality materials and reliable operation. It is suitable for a wide range of applications: industrial machinery, assembly lines, control panels, drive panels, elevators, goods lifts, parking systems and construction equipment. Easy to install; contact modules are replaceable.

References

• D-7500
• D-7501
• D-7503
• D-7504
• D-7505
• D-7506
• D-7506P
• D-7507
• D-7508-2
• D-7508-3
• D-7509
• D-7509N
• D-7510
• D-7511
• D-7512
• D-7513
• D-7514
• D-7515
• D-7516
• D-7517
• D-7518
• D-7519

General characteristics
Mounting: Panel
Panel hole diameter: 22 mm
Voltages: AC/DC 24V; AC 220V
Rated current: 15 Amperes
Connection: Terminals
Material: Polycarbonate (PC) 135°
Front protection: IP55
Colors: Red, Green, Amber, Clear, Blue, Black

Features / Technical specifications

• Series: 7500 (replaceable contact modules)
• Applications: industrial machinery, assembly lines, control panels, drive panels, elevators, goods lifts, parking systems, construction equipment
• Mounting type: Panel
• Drill diameter: 22 mm
• Supported voltages: AC/DC 24V; AC 220V
• Rated current: 15 A
• Connection type: Terminals
• Housing material: Polycarbonate (PC) 135°
• Front protection rating: IP55
• Available colours: Red, Green, Amber, Clear, Blue, Black
