ATX motherboard SNA610

AMD EPYC™AMDRAM

- AMD EPYC™ 8004 processors - 6 DDR5 ECC-RDIMM up to 576GB - Single Display: DP - Supports 4K high resolution - Multiple Expansion: 3 PCIe x16 (Gen5), 3 PCIe x8 (Gen5), 1 PCIe x4 (Gen5), 2 M.2 M key 2280 - Rich I/O: 2 GbE + 2 10GbE, 1 Dedicated IPMI LAN, 6 USB 3.2 Gen1, 2 USB 2.0, 2 COM, 1 Vertical USB 2.0 - IPMI/Redfish OOB Remote Management Technical Specifications: - Processor: AMD EPYC™ 8004 processors LGA4844, TDP up to 225W: - AMD EPYC™ 8534P (64 cores, up to 3.1GHz); 200W - AMD EPYC™ 8434P (48 cores, up to 3.1GHz); 200W - AMD EPYC™ 8324P (32 cores, up to 3.0GHz); 180W - AMD EPYC™ 8224P (24 cores, up to 3.0GHz); 160W - AMD EPYC™ 8124P (16 cores, up to 3.0GHz); 125W - Memory: 6 x ECC-RDIMM up to 576GB, DDR5 Max. 4800MHz - BIOS: Insyde - Graphics Controller: BMC AST2600 - Display: 1 x DP (DisplayPort) - Expansion: 3 x PCIe x16 (Gen5), 3 x PCIe x8 (Gen5), 1 x PCIe x4 (Gen5), 2 x M.2 M key 2280 - Audio Codec: HS-100B - Ethernet Controllers: 1 x Intel® I210AT, 1 x Intel® I226LM, 2 x Intel® E610-XAT2, IPMI: RTL8211F - Rear I/O: 2 x GbE + 2 x 10GbE, 1 x Dedicated IPMI LAN, 1 x RS-232/422/485 (DB-9), 4 x USB 3.2 Gen1, 1 x DP - Internal I/O: 1 x RS-232/422/485, 2 x USB 3.2 Gen1, 2 x USB 2.0, 1 x Vertical USB 2.0, 1 x Front Audio, 4 x SATA 3.0 (RAID 0/1/5/10), 16-bit DIO, 1 x SMBus, 1 x MCIO (PCIe x8) - Security: TPM 2.0 - Power Type: ATX - Environment: Operating Temperature: 0 to 60°C, Operating Humidity: 5 to 95% RH, Storage Humidity: 5 to 95% RH, MTBF: TBD - Mechanism: ATX Form Factor, Dimensions: 305mm (12") x 244mm (9.6"), Height: PCB/Top/Bottom Side: TBD - Packing List: SNA610 Motherboard (770-SNA6101-000G), 2 M.2 screws (A32-112016-041G), 2 M.2 standoffs (A33-725019-090G), 1 IO Shield, 1 Serial ATA data cable (Length: 500mm, 332-553001-005G) - Country of Origin: Taiwan
