Plate and frame filter press iONIC

membranerobotizedremote-controlled

Overview
The Diefenbach iONIC filter press is industrial liquid‑solid separation equipment engineered for dewatering highly acidic and corrosive sludges. It is adapted to applications such as lead and lithium battery recycling and other aggressive chemical environments where corrosion resistance is required.

How Diefenbach iONIC Filter Presses Work
The iONIC uses recessed or membrane filter plates that form filtration chambers when closed. Acidic slurry is pumped into the press from both ends (dual feed) to achieve uniform chamber filling. Solids are retained on filter cloths mounted on the plates while filtrate passes through the cloths and exits the press. At the end of a cycle the plates open and the solid cakes are discharged.

Features & Benefits

• Construction in stainless steel with specialized protective coatings where required to resist chemical attack.
• Choice of recessed (chamber) or membrane plates to match dewatering needs.
• Dual slurry feed (both ends) for optimal chamber filling and process balance.
• Single hydraulic cylinder main drive to ensure reliable plate synchronization and controlled closing force.
• Core‑blow function to clear the central feed port and improve cake dryness; optional cake drying stages available.
• Robotic high‑pressure automated wash system available (up to 100 bar / 1450 psi) to clean filter cloths and reduce operator exposure.
• Advanced automation and remote monitoring/assistance packages to support process control and diagnostics.
• Manufacturer support and service options for installation, commissioning and long‑term maintenance.

Applications
Designed for dewatering highly acidic and corrosive sludges, including lead and lithium battery recycling, demanding chemical processing applications and any industry handling aggressive slurries requiring corrosion‑resistant separation equipment.

Resources

• Types of filter plates (recessed and membrane)
• Filter press plate opening systems and configurations
• Laboratory testing and pilot trials for feed characterization and optimal press design

Technical specifications

• Manufacturer: Diefenbach
• Model / Series: iONIC
• Construction materials: stainless steel with specialized protective coatings as required
• Filter plate types: recessed (chamber) plates or membrane plates
• Feed: dual slurry feed, pumped from both ends for optimal chamber filling
• Main drive: single hydraulic cylinder for plate closing and guaranteed synchronization
• Wash system: robotic automated wash available, up to 100 bar (1450 psi)
• Operation: chambers formed by plates; solids retained on cloths; filtrate exits through cloths; plates open to discharge cakes
• Drying options: core blow to remove slurry from central feed port; optional cake drying step
• Automation: advanced automation and remote monitoring packages available
• Service: manufacturer support for installation, commissioning and maintenance
• Primary applications: processing highly acidic and corrosive sludges; lead and lithium battery recycling
