Portable loudspeaker BExL15/BExDL15, BExL25/BExDL25
explosion-proof

portable loudspeaker
portable loudspeaker
portable loudspeaker
Add to favorites
Compare this product


Characteristics

Mounting
portable
Other characteristics
explosion-proof
Sound level

102 dB, 113 dB

Description

BExL15/BExDL15 PA Loudspeakers 15W & BExL25 / BExDL25 PA Loudspeakers The flameproof BEx PA loudspeakers are suitable for Zone 1 & Zone 2 applications and the sounders also for Zone 21 & 22. The BEx range features enclosures manufactured from corrosion proof, marine grade copper free LM6 aluminium which is phosphated and powder coated. The re-entrant flare horns are high impact, fire retardant ABS. All models have two M20 cable entries, large termination areas containing in & out terminals (Ex de version only) and an ingress protection of IP66/67 (Ex d) and IP66 (Ex de). An independent test report is available on request, or online, detailing the performance of the BEx loudspeaker range. Features: Very large termination area. Ratchet adjustable stainless steel U bracket. IN & OUT terminals (Ex de version only). Approvals: ATEX certicate: KEMA 99ATEX6312, EN 60079-0 : 2006, EN 60079-1 : 2007, EN 60079-7 : 2003, EN 61241-0 : 2006, EN 61241-1 : 2004 IECEx certicate: IECEx KEM 10.0003, IEC 60079-0 : 2004 (Ed4), IEC 60079-1 : 2007 (Ed6), IEC 60079-7 : 2001 (Ed3), IEC 61241-0 : 2004 (Ed1), IEC 61241-1 : 2004 (Ed1) GOST-R certicate: POCC GB.JB05. B03365 Safety-integrity suitability: SIL1 Inmetro certicate: 10-IEx-0009
