Flash chromatography system ECS22

laboratoryfor pharmaceutical applicationsfor chemical applications

A highly effective preparative system containing a UV DAD detector, a preparative pump, a fraction collector, and a box for bottles. The detector allows measuring at four wavelengths at the same time or an informative scan. Communication is through RS232 or Ethernet (LAN). An additional PC A/D converter card is not required for this system. The system contains a manual injector and ECOMAC software which include drivers for all ECOM units. A wireless mouse and keyboard set (P/N: EPC-0028), a PC (P/N: EPC-0026) and a computer monitor (P/N: EPC-0027) can be purchased with the system. Main parts TOY18DAD H 400 DETECTOR is a UV-VIS diode array detector, which allows measuring the absorbance of four wavelengths in the range of 200 – 400 nm simultaneously in one cell just as visualization of whole spectra. It is possible to use the detector in flash and preparative applications. Standardly is assembled preparative cell PLCC 15 but other cells are available. ECP2200 PREPARATIVE PUMP This isocratic pump works with a flow rate range of 0.1-250 ml/min and pressures up to 30 MPa. Unit software includes a new learning algorithm for pulsation suppression and many testing and diagnostic functions. ECV2010 FRACTION COLLECTOR The fraction collector is equipped with a selector rotary valve with 10 positions. It is used in applications if the number of collected fractions is low. ECB2006 BOX FOR MOBILE PHASE BOTTLES The box is suited for secure mobile phase bottle installation onto isocratic systems.
