Wall thickness gauge MTG4
materialsultrasonichandheld

wall thickness gauge
wall thickness gauge
wall thickness gauge
wall thickness gauge
Add to favorites
Compare this product


Characteristics

Applications
wall, materials
Technology
ultrasonic
Other characteristics
handheld
Measuring range

Max.: 20 mm (0.79 in)

Min.: 0 mm (0 in)

Description

With a choice of calibration options and measurement modes, the MTG4 is ideal for taking readings on a wide range of coated and uncoated materials. As well as all the features of the MTG2, the MTG4 has two calibration options. Using an uncoated sample of test material of a known thickness, the gauge can be calibrated using 1-Point calibration. Alternatively, the user can select one of 39 pre-set materials stored within the gauge including; aluminium, steel, stainless steel, cast iron, plexiglass, PVC, polystyrene and polyurethane. Measurement Mode Echo-Echo ThruPaint™ (E-E) measurement mode enables readings to be taken on coated materials with a thickness range up to 20.00mm (0.787”). In Echo-Echo ThruPaint™ mode, the coating thickness is ignored and the material thickness from the top surface of the material to the material density boundary is displayed. Data Output Compatible with ElcoMaster® software, individual readings can be downloaded via USB to PC or similar device for further analysis.
