Polyamide cam lever GN 927.4stainless steelthreaded
Add to favorites
Compare this product
Characteristics
- Material
- polyamide, stainless steel
- Other characteristics
- threaded
Description
LEVER BODY
Die-cast zinc alloy, epoxy resin coating, RAL 9005 black colour, matte
finish.
ROTATING PIN
AISI 303 stainless steel.
CLAMPING ELEMENT
AISI 303 stainless steel with threaded hole or threaded screw.
STANDARD EXECUTIONS
- GN 927.4-A-B: AISI 303 stainless steel support bushing with glass-fibre
reinforced acetal resin based (POM) technopolymer contact insert
and AISI 303 stainless steel threaded embossed base.
- GN 927.4-B-B: glass-fibre reinforced polyamide based (PA)
technopolymer support bushing.
FEATURES AND APPLICATIONS
GN 927.4 cam clamping levers are suitable for quick clamping. Turning
the support bushing allows the operator to adjust the clamping force
to be applied through the lever and simultaneously determine the most
suitable position that the lever must assume once the clamping has
been carried out.
SPECIAL EXECUTIONS ON REQUEST
Lever body in RAL 2004 orange, RAL 3000 red or RAL 9006 grey colour.
