Carrier board SK2-SESSION

SK2-SESSION is a bidirectional 4-lane PCI Express® Gen3 redriver, for optimum 8GT/s high speed signal integrity, and can be installed into any peripheral slot of a CompactPCI® Serial backplane. Product Features PICMG® CompactPCI® Serial standard (CPCI-S.0) peripheral slot card) -12V regulator option (J15 Pin F8) Single size Eurocard 3U 4HP 100x160mm CPCI-S backplane connector P1 & P2 (fat pipe slot up to PCIe® x 4) XMC Module Connector J15 (originally defined by VITA 42 as PCIe Gen1 interface) Option XMC 2.0 Module Connector J15 (VITA 61) recommended for PCIe Gen2/Gen3 4 x PCI Express® lanes Gen1 (2.5GT/s), Gen2 (5.0GT/s) or Gen3 (8GT/s) 4-Lane bidirectional PCIe Gen3 redriver/repeater for optimum signal integrity PCI Express® Gen3 clock buffer for optimum signal integrity +12V XMC VPWR
