Expansion PC NPC-7522

AImobileNVIDIA® Jetson AGX Xavier™

Product Overview
Redefining the Boundaries of Robotic Intelligence
At the heart of this product lies the NVIDIA® Jetson AGX THOR module, boasting a peak performance of 2070 TOPS. It can effortlessly handle multiple HD video streams, run complex deep learning models, and perform real-time environmental perception and decision-making. With support for up to 128 GB of memory, it ensures smooth and stable operation for large-scale AI applications and massive data processing, completely eliminating performance bottlenecks and empowering robots to tackle unprecedented intelligent challenges.

Precise Positioning, Systemic Advantages: Bestowing "Intelligence" and "Senses" upon High-End Robots
The product is precisely positioned for the AI robotics field. Its design philosophy deeply integrates powerful computing with comprehensive environmental interaction capabilities. This is reflected not only in the 2070 TOPS core but also in its tailored interface ecosystem:

• "Keen Eyes": Support for up to 8 channels of GMSL2 video input allows the robot to be equipped with multi-camera setups and depth sensors (like LiDAR), enabling 360° environmental perception and laying the foundation for autonomous navigation and precise operation.
• "Agile Body": Abundant industrial buses including 4x CAN, 2x RS485, and 32-bit GPIO allow it to easily connect and control the robot's servo drives, robotic arm joints, and various sensors, enabling precise movement and manipulation.
• "High-Speed Nerves": The optional 10GbE network ports ensure lossless, high-speed transmission of massive perception data between internal subsystems, while 4G/5G and Wi-Fi 6 form the real-time communication "lifeline" between the robot and the cloud or control center.

This systematic interface design transforms the product from a mere computing unit into the true nerve center for the robot's "Perception-Decision-Action-Interaction" closed loop.

Easy connection, simplified deployment
This product offers a rich and versatile interface configuration, ensuring strong connection capabilities and convenient deployment:

• Universal network architecture: Equipped with 5 gigabit and 2 optional 10-gigabit (2.5G/5G/10G) standard RJ45 interfaces, compatible with most existing network infrastructures, with convenient wiring and low cost, capable of fully meeting the requirements for high-speed data transmission and equipment networking.
• Environmental sensing: Through 2 mini Fakra Max interfaces, up to 8 GMSL2 cameras can be connected, forming a complete visual sensing system.
• Industrial control and expansion: Integrated with 4x CAN, 1x RS232, 2x RS485 and 32-bit GPIO industrial buses, capable of stable connection and control of various actuators and sensors. Also provides 4 USB 3.2 and 1 Type-C interfaces, facilitating connection of various peripherals.
• Wireless and positioning: Supports Wi-Fi 5/6, 4G/5G mobile networks, and integrates GNSS and TPM 2.0 security modules, ensuring mobile connection, precise positioning and data security.

Reliable Quality Assurance
Adopting industrial-grade reliability standards, it supports a wide voltage range of 9~36V for power supply, and is equipped with overvoltage and overcurrent protection mechanisms to ensure the stable operation of the equipment in complex industrial environments. The streamlined design not only reduces the complexity of the system but also enhances the overall reliability.

Features

• The Jetson AGX THOR module is adopted
• Supports up to 128GB Memory and 2070TOPS
• Support up to 14-core Arm® Neoverse®-V3AE 64-bit • 5*GbE, 2*LAN (2.5G/5G/10G optional)
• 4 x USB3.2 Type-A,1 x USB3.2 Type-C
• Up to 8 channels of GMSL2 access
• Supports WiFi, Bluetooth, 4G/5G, TPM 2.0, and GNSS
• Supports CAN bus and RS232/485 serial ports
• Industrial-grade equipment
• DC 9~36V wide voltage power supply, overcurrent and overvoltage protection

Specifications

• Processor: 12-core Arm® Neoverse®-V3AE 64-bit, 14-core Arm® Neoverse®-V3AE 64-bit
• GPU: 1536-core NVIDIA Blackwell architecture GPU with 64 fifth-gen Tensor Cores Multi-Instance GPU (MIG) with 6 TPCs, 2560-core NVIDIA Blackwell architecture GPU with 96 fifth-gen Tensor Cores Multi-Instance GPU (MIG) with 10 TPCs
• NPU: 1200 Sparse FP4 TFLOPs, 600 Sparse/300 Dense FP8 TFLOPs, 2070 Sparse FP4 TFLOPs, 1035 Sparse/500 Dense FP8 TFLOPs
• Memory: 64GB/128GB
• Storage: M.2 M Key 2280 NVMe
• LAN: 5 x RJ45, 10/100/1000 MBPS; 2 x RJ45 (2.5G/5G/10G optional)
• Audio: 1 x 3.5mm Combo Jack, 1 x 12-pin vehicle connector: 4 x DMIC, 2 x 5W AMP
• Display: NVIDIA Blackwell GPU, Input: 2 x mini Fakra max (up to 8 channels of GMSL2 access), Output: 2 x HDMI2.1, Up to 4096 x 2160 @60Hz
• USB: 4 x USB3.2 Type-A, 1 x USB3.2 Type-C
• LED: 9 x LED (1x power supply, 1x hard disk indicator light, 7x network port light)
• Button: 1 x power button, 1 x Recovery button
• Extension: 1x28-pin vehicle connectors: 4x CAN, 1x RS232, 2x RS485, 1x40-pin vehicle-mounted connector: 32-bit GPIO (with 16-bit optocoupler isolation)
• TPM: TPM 2.0
• Watchdog: 255 levels of programmable seconds per minute
• OS Support: Ubuntu24.04 (Jetpack7.0)
• Power Input: 9~36V DC IN
• Dimensions: 130x125x85mm
• Net Weight: kg
• Operating Temp.: -25~60℃ (-13~140 °F) w/ 0.7m/s airflow
• Storage Temp.: -40~85℃ (-40~185 °F)
• Humidity: 10% to 90% no condensation
• Shock: With SSD solid-state drive: Operating state, 2Grs@5~500Hz, IEC 60068-2-64
• Vibration: With SSD solid-state drive: working state, 15G@11ms half sine wave
• EMC: CE/FCC
