3/4-axis CNC milling machine TH-3013NCswiveling-spindlerotating tablecutting
Add to favorites
Compare this product
Characteristics
- Number of axes
- 3/4-axis
- Spindle orientation
- swiveling-spindle
- Structure
- rotating table
- Associated functions
- cutting
- Applications
- for furniture
- Other characteristics
- duplex
- X travel
3,000 mm
(118.11 in)- Y travel
Max.: 1,350 mm
(53.15 in)Min.: 90 mm
(3.54 in)- Z travel
290 mm
(11.42 in)- Rotational speed
Max.: 600 rpm
(3,770 rad.min-1)Min.: 50 rpm
(314 rad.min-1)- Power
Max.: 750 kW
(1,019.72 hp)Min.: 15 kW
(20.39 hp)- Table load capacity
6,000 kg
(13,228 lb)- Weight
18,000 kg
(39,683.21 lb)- Overall length
8,300 mm
(326.8 in)- Overall width
4,100 mm
(161.4 in)- Overall height
2,500 mm
(98.4 in)
Description
Product overview
ESTOP Duplex Milling Machine TH-3013NC is a CNC head moving type duplex milling machine designed for machining large panels and heavy workpieces in industrial production environments.
Applications
Technical specifications
Tags
ESTOP Duplex Milling Machine TH-3013NC is a CNC head moving type duplex milling machine designed for machining large panels and heavy workpieces in industrial production environments.
Applications
- Panel and board milling for furniture and joinery production
- Processing of composite and laminated panels
- Integration into automated cutting and processing lines
Technical specifications
- Model: TH-3013NC
- Control system: (LNC)
- Cutting width: 90–1350 mm
- Maximum cutting length: 3000 mm
- Maximum cutting thickness: 290 mm
- Rotating disc diameter: 630 mm
- Rotating disc tabletop size: 800 x 800 mm
- Workbench size (L x W): 3850 x 720 mm
- Cutting disks diameter: 300 mm
- Spindle speed range: 50–600 r.p.m
- Spindle configuration: gear power head
- Spindle motor power range: 15–750 kW
- Servo motors: X-axis 5.5 kW; Y-axis 5.3 kW; Z-axis 5.3 kW; C-axis 3 kW
- Maximum workbench load capacity: 6000 Kg
- Approximate machine weight: 18000 Kg
- Overall size (L x W x H): 8300 x 4100 x 2500 mm
Tags
- Duplex
- milling
- machine
