Elastomer coupling EK seriescompactlow-backlashbacklash-free
Add to favorites
Compare this product
Characteristics
- Type
- elastomer
- Other characteristics
- compact, backlash-free, low-backlash
- Installation system
- set screw
- Torque
Max.: 12,500 Nm
(9,219.5269 ft.lb)Min.: 0.5 Nm
(0.3688 ft.lb)- Rotational speed
Max.: 15,000 rpm
(94,247.78 rad.min-1)Min.: 0 rpm
(0 rad.min-1)
Description
Elastomer Coupling EK1
Two coupling hubs are concentrically machined with curved jaws
• Bore tolerance
• keyway
• set screw or optional pilot bore
• Economical design
• concentrically machined
• vibration damping
• electrically isolating
• press fit design
• low backlash due to keyway connection
0,5 - 1100 Nm
Elastomer Coupling EK2
Two coupling hubs are concentrically machined with curved jaws
• Easy assembly
• concentrically machined hubs
• vibration damping
• backlash free
• electrically isolating
• press fit design.
6 - 1100 Nm
Elastomer Coupling EKL
Two coupling hubs are concentrically machined with curved jaws
• Short compact design
• easy assembly
• vibration damping
• electrically isolating
• press fit design
• backlash free
0,5 - 1100 Nm
Elastomer Coupling EKH
Both clamping hubs are fully separable due to split hubs and ISO 4762 clamping screws
• Lateral mounting possible
• concentrically machined hubs
• vibration damping
• electrically isolating
• easy mounting
• backlash free
4 - 12.500 Nm
