Zero-backlash couplings

Torque: 1.28 Nm - 294.97 Nm
Rotational speed: 3,150 rpm - 25,400 rpm

... hub to shaft. Zero or minimum backlash. Torque capacity of coupling determined by bore size. Clamping Hub With Double Slot With Keyway (DSCK) – Transmits torque utilizing a double split ...

Torque: 240 Nm - 147,000 Nm
Rotational speed: 1,740 rpm - 22,700 rpm

... conditions Larger sizes are available upon request ATEX Certified The SU Type coupling consists of: Two – Hubs One – 6 Bolt Disc Pack Kit This coupling is only suitable for the specified ...

Torque: 100 Nm - 440,000 Nm
Rotational speed: 1,440 rpm - 22,700 rpm

... No wearing parts and high resistance ATEX Certified The SX Type coupling consists of: Two – Hubs One – Spacer 2 – Disc Pack Kits (4, 6 or 8 bolt) The coupling has two flex planes ...

Torque: 590 Nm - 8,500 Nm

... types, and Power Locks with reinforced plastic spacers. ・Non-backlash ・No lubrication ・Longevity Ideal for equipment that positions with a servomotor as the coupling has no backlash ...

Torque: 60 Nm - 810 Nm

... and stopping. ・With the combination of the optimally designed spider and hub, this Jaw-Flex Coupling series is capable of transmitting torque without backlash. ・You can choose from between two types ...

Torque: 150 Nm - 17,560 Nm
Rotational speed: 3,100 rpm - 19,500 rpm

... radial reaction forces Alternative to flexible coupling This is a suitable alternative to flexible couplings whenever the environmental conditions are detrimental to the elastomer. DISCFLEX couplings ...

Torque: 8,000 Nm - 160,000 Nm
Rotational speed: 1,040 rpm - 2,100 rpm

The RATO DG and RATO DG+ engine drive couplings have been specially designed for use in installations requiring a medium level of torsional flexibility and misalignment capacity. These couplings are used ...

Torque: 6,300 Nm - 160,000 Nm
Rotational speed: 1,040 rpm - 2,100 rpm

... steady-state torsional vibration response. In the tradition of VULKAN Couplings, a backlash-free torque transmission is achieved. Benefits Vulkan Rato DS and RATO DS+ marine couplings ...

Torque: 35 Nm - 150 Nm
Rotational speed: 7,800 rpm - 22,500 rpm

... technical specifications. ROBA-DS couplings are shaft connections and transmit torsionally stiff and backlash-free torque. At the same time, they compensate for angular and axial misalignments in single-jointed ...

Torque: 4 Nm - 2,080 Nm
Rotational speed: 3,000 rpm - 28,000 rpm

... . ROBA® -ES couplings connect shafts in highly dynamic servo drives. They transmit torques elastically and backlash-free. Single-jointed couplings (type 940.___) compensate for axial ...

Torque: 16 Nm - 700 Nm
Rotational speed: 2,500 rpm - 10,000 rpm

... optimally to your technical specifications. smartflex® are plug-in metal bellows couplings They connect shafts and transmit torques torsionally stiff and backlash-free. They compensate for angular ...

Torque: 0.25 Nm - 250 Nm
Rotational speed: 0 rpm - 10,000 rpm

The Single Flex SA2 version of the Servoflex SFC series impresses with its extremely high torsional stiffness combined with possible compensation in axial and angular direction. Due to the light and high-strength aluminum alloy it has ...

Torque: 0.25 Nm - 250 Nm
Rotational speed: 0 rpm - 10,000 rpm

The Double Flex DA2 version of the Servoflex SFC series impresses with its high torsional stiffness including a possible compensation function in axial, parallel and angular direction. Due to the light and high-strength aluminum alloy, ...

Torque: 2 Nm - 400 Nm
Rotational speed: 3,500 rpm - 40,000 rpm

... material selection and adaptation to customer specific lengths. - Zero Backlash - Good flexibility - Length possible to customize

The GS Shat Coupling is a special anti-backlash shaft coupling. The toothed ring is installed under pre-tension, resulting in a low surface pressure and hence increased rigidity of the ...

Torque: 96 Nm - 18,700 Nm
Rotational speed: 3,600 rpm - 7,500 rpm

with double disc packs, design according to API 610 Features High torque capacity Backlash free Compensation of axial, radial and angular misalignments Double disc pack allows smooth torque transmission High ...

Torque: 15,000 Nm
Rotational speed: 19,000 rpm

Spider couplings, also known as jaw couplings, are torsionally flexible shaft couplings which enable the connection of shafts or flanges via a polyurethane drive ring. Parallel, angular ...

Torque: 5,000 Nm
Rotational speed: 2,500 rpm - 10,000 rpm

This range of torsional couplings solve torsional vibration problems typical of those found in diesel engine applications. The torsional coupling dampens torsional vibrations and tunes the system to have ...

Torque: 0.1 Nm - 5,000 Nm
Rotational speed: 2,800 rpm - 15,000 rpm

Bellows couplings are the perfect coupling for all servo motor applications where high torsional rigidity, truly backlash free torque transmission, low inertia, and superior ...

Torque: 0.5 Nm - 100 Nm
Rotational speed: 15,000 rpm

Metal bellows couplings, mini with grub screw MATERIAL Hub aluminium. Bellows stainless steel. VERSION Bright. NOTE Play-free mini metal bellows coupling with high torsional stiffness. The ...

Torque: 1.1 Nm - 77 Nm

Rigid couplings one-piece Material: Steel 1.0718. Stainless steel 1.4305. Version: Bright. Note: Rigid couplings transmit high torques without rotational play. They are used where there are no shaft ...

Torque: 20 Nm - 5,333 Nm
Rotational speed: 3,000 rpm - 14,000 rpm

The Single Flex 6A-C version of the backlash-free composite disc coupling enables the compensation of very high shaft misalignments in axial and angular direction. The compact design of the single cardanic ...

Torque: 20 Nm - 5,333 Nm
Rotational speed: 3,000 rpm - 14,000 rpm

The single-cardanic Single Flex 6A version of the backlash-free composite disc coupling allows compensation of very high shaft misalignments in axial and angular direction. As standard, the classic Single ...

Torque: 20 Nm - 282 Nm
Rotational speed: 6,700 rpm - 15,000 rpm

The Single Flex 6A-A1C version of the backlash-free composite disc coupling allows compensation of very high shaft misalignments in axial and angular direction. The compact aluminum clamping hub design ...

Torque: 200 Nm - 110,000 Nm
Rotational speed: 1,300 rpm - 4,200 rpm

... torsionally flexible rubber disc coupling for internal combustion engine drives * Very high torsional flexibility with a linear torsional deflection characteristic * High torsional vibration and shock load absorbing capability * ...

Torque: 100 Nm - 10,000 Nm
Rotational speed: 1,800 rpm - 10,000 rpm

TOK Coupling System TOK Coupling System * Elements available in different torsional stiffnesses * Suited for highest speeds * Adaptation to DIN or SAE flanges or according to specification * Self-centering, ...

Torque: 160 Nm - 54,000 Nm
Rotational speed: 900 rpm - 4,500 rpm

... flexible coupling with progressive torsional stiffness MULTI CROSS FORTE MCF * Very high torsional flexibility with a progressive torsional characteristic line * High compensation capability of axial, radial and angular ...

Torque: 0.18 Nm - 50.7 Nm
Rotational speed: 30,000, 45,000, 35,000 rpm

... connecting two shaft ends. The MIC-5 (double-element coupling) also provides compensation for radial misalignment. On demand, MIC Series Couplings are available in an electrically isolated version, ...

Water Industry Couplings Easy access – drive reset in minutes. Wedge construction gives maximum rigidity with no backlash. Ideal for indexing or reversing drives. Clamping screws give positive axial ...

Torque: 8,000 Nm - 160,000 Nm
Rotational speed: 1,040 rpm - 2,100 rpm

The RATO DG and RATO DG+ engine drive couplings have been specially designed for use in installations requiring a medium level of torsional flexibility and misalignment capacity. These couplings are used ...

Torque: 6,300 Nm - 160,000 Nm
Rotational speed: 1,040 rpm - 1,040 rpm

... steady-state torsional vibration response. In the tradition of VULKAN Couplings, a backlash-free torque transmission is achieved. Benefits Vulkan Rato DS and RATO DS+ marine couplings ...

Quick plug coupling, adjustable without axial play, including angular and radial offset compensation. Suitable for multiple applications, e.g. for non-aligned linear movements. Solid and compact design, ...

Torque: 1.1 Nm - 65 Nm
Rotational speed: 9,000 rad.min-1 - 42,000 rad.min-1

... equipment / Mount machines / Medical / Machine tools / Packaging machines ● Optional Services -Couplings Bore and Keyway Additional Modification Service -Coupling Stainless Steel Screw Alteration Service -Cleanroom ...

Torque: 1.1 Nm - 35 Nm

... Actuator / Surface-mount machine / High precision XY stage / Index table Optional Services -Couplings Bore and Keyway Additional Modification Service -Coupling Stainless Steel Screw Alteration Service Please ...

Torque: 0.6 Nm - 200 Nm
Rotational speed: 6,000 rpm - 42,000 rpm

... for 1/10 taper shaft & clamping type) XHS-C (short, clamping type) Optional Services -Couplings Bore and Keyway Additional Modification Service -Coupling Stainless Steel Screw Alteration Service Application Actuator ...

Torque: 20 Nm - 1,600 Nm
Rotational speed: 300 rpm - 3,500 rpm

• customized length up to 3 m • plug in, backlash free, oszillation dampening • split- hub on both sides • stainless design (aluminum) • Torque range: 20 - 1600 Nm • Shaft diameter: 10 - 100 mm • temperature range: ...

Torque: 4 Nm - 1,000 Nm
Rotational speed: 8,000 rpm - 20,000 rpm

• variable lengths from 55 to 260 mm • without additional intermediate storage • backlash-free, precise torque transmission • special symmetrical clamping hub with high balancing quality and for high operating speeds

Torque: 8 Nm - 2,000 Nm
Rotational speed: 6,000 rpm - 29,000 rpm

• radial clamping hub on both sides • cost-effective, very short design, standard series • plug in, backlash free, oscillation dampening • Torque range: 8 - 2.000 Nm • Shaft diameter: 8 - 90 mm

• Under initial tension no backlash shaft connection • Triple axially pluggable version • Simple blind mounting, no time-consuming screwings • Small structural dimensions – low flywheel effects • ...

Torque: 0.05 Nm - 10 Nm
Rotational speed: 0 rpm - 15,000 rpm

Miniature Metal Bellows Coupling with set screws  • Backlash-free miniature metal bellows coupling with radial set screws  • For shaft diameters from 1 – 24 mm  • High ...

Torque: 0.1 Nm - 10 Nm
Rotational speed: 0 rpm - 15,000 rpm

... Perfect bellows coupling for encoders, tachometers, potentiometers, servo drives, NC axis, stepper motors  • Torque range: 0,1 – 10Nm Miniature Metal Bellows Coupling with split hubs  • Backlash-free ...

Torque: 18 Nm - 1,400 Nm

Metal Bellows Coupling with collet clamps  • Backlash-free metal bellows coupling with clamp hubs  • Hub material: up to 60Nm – aluminum, up from 80Nm - steel  • For shaft ...

Torque: 3 Nm
Rotational speed: 6,000 rpm

Corrosion proof HKS metal multiple disc couplings compensate an angular offset up to 0.5° and an axial misalignment up to ±1 mm as well as extending the service life of encoders in the process. They are ...

Torque: 0 Nm - 5 Nm
Rotational speed: 0 rpm - 8,000 rpm

Corrosion proof HKD metal multiple disc couplings compensate a parallel misalignment up to ±0.5 mm and an axial misalignment up to ±1.5 mm as well as extending the service life of encoders in the process. ...

Torque: 3 Nm
Rotational speed: 6,000 rpm

Corrosion proof HKDS metal multiple disc couplings compensate a radial offset up to 0.5 mm and an axial misalignment up to ±1.5 mm as well as extending the service life of encoders in the process. They ...
